Medical use titanium rod : |
ASTM F67 (Grade 1-4), ASTM F136 (Grade 5,Grade 23) |
Name | Medical titanium bar/rod |
Medical grade titanium bar/rod | |
Medical titanium alloy bar/rod | |
Medical grade titanium alloy bar/rod | |
Standard | ASTM F136 |
Grade | |
Gr5Eli,Gr23 | |
Diameter | Titanium bar for bone screw:6mm,8mm, 10mm,12mm |
Titanium bar for intramedullary13.5mm, 14.5mm, 16mm | |
Titanium bar for dental:8mm, 20mm, 25mm,30mm | |
Titanium bar for bone joint:30mm, 40mm, 65mm | |
Length | 1000mm/3000mm/6000mm |
Tolerance | h6,h7,h8,h9 |
Technique | Forging ,Machining |
Surface | acid surface or polishing, sand blasted surface |
Shape | Round, flat, square, hexagonal,hollow |
Application | 1.Pins |
2.Bone plates | |
3.Screws | |
4.Bars | |
5.Rods | |
6.Wires | |
7.Posts | |
8.Expandable rib cages | |
9.Spinal fusion cages | |
10.Finger and toe replacements | |
11.Maxio-facial prosthetics |
Titanium is a chemical element, the chemical symbol Ti, atomic number 22, is a silver-white transition metal, characterized by light weight, high strength, metallic luster, but also has good corrosion resistance (including seawater, king water and chlorine). Because of its stable chemical properties, good resistance to high temperature, low temperature, strong acid, strong alkali, as well as high strength, low density, has been praised as "space metal." Titanium was discovered by Gregor in Cornwall, England, in 1791 and named after the Greek mythical Titan by Clapert. Titanium is widely used in the medical field. Titanium is close to human bones and has good biocompatibility and non-toxic side effects on human tissue. Human implants are special functional materials closely related to human life and health. Compared with other metal materials,.
The advantages of using titanium and titanium alloys mainly include the following:
1. Light weight
2 . Low elastic modulus
3. Non-magnetic
4 . Non-toxic
5 . Corrosion resistance
6 . High strength, good toughness
The amount of titanium alloy used in surgical implants is increasing at a rate of 5%-7% per year. The use of titanium and titanium alloy manufactured femoral bones, hips, tibia, skull, knee, elbow, shoulder, palm finger, jaw and cardiodeterus membrane, kidney membrane, vascular dilater, splints, prosthesis, fastening screws and other hundreds of metal parts transplanted into the human body, achieved good results, has been highly rated by the medical community.
Iproducts | Titanium medical use bar ASTM F67 ASTM F136 EIL ti bar ti rod |
Application | medical use |
Type | GR1, GR5, 6AL4V Eli, GR23 |
Standard | ASTM F136,ASTM F67 ELI |
Certificate | ISO 9001:2008 |
Manufacturing process: | Hot forging hot rolling turning (polishing) |
Supply Ability | 10 Tons per Mon |
