Keyword: | Titanium Copper CLAD BAR For Electrolysis Under Strong Corrosion Conditions | Material: | Copper T2 Titanium Gr2 |
---|---|---|---|
Standard: | ASTM B432 GB/T12769-2003 | Diameter: | As Order |
Length: | 200mm - 6000mm | Advantage:: | Acid Resistance High Performance |
Technology: | Rolled | Name: | TI CU CLAD BAR |
Highlight: | Gr2 Titanium Clad Copper Rod,Titanium Clad Copper Rod,ASTM B432 Titanium Square Rod |
High-quality Pure Ti Cladding Material Industrial Titanium Clad Copper Bar
For Electroplating
Titanium copper composite rod also known as titanium clad copper, a certain thickness of titanium layer is coated on a copper rod, which is the main component of the metal anode. It combines the excellent conductivity of copper with the excellent corrosion resistance of titanium. It is mainly used in electrolysis, electroplating, hydrometallurgy and metal anode electrolysis cell under the condition of strong corrosion. It is a kind of high quality electrode material.
Titanium Clad Copper | |
Substrate | Copper T1 T2; Aluminium, etc. |
Specification | Round: 6.35 - 78mm |
Rectangle: width 20mm - 150mm x thickness 6mm - 30mm | |
Flat: side length 10mm - 30mm | |
(Other materials and specifications can be produced according to customer requirements.) | |
Cladding Materials | Titanium, Zirconium, Nickel, Stainless steel(304, 316L), etc. |
Cladding Thickness | Normally 1.0mm - 2.5mm |
Standard | GB/T12769-2003 ASTM B432 |
Wire: 2 - 6.35mm | |
Shape | round, drum-shaped, square, flat |
Application | electrolysis, electroplating, hydrometallurgy and metal anode electrolysis cell |
Titanium Clad Copper | |
Standard | GB/T12769-2003 ASTM B432 |
Specification | Wire: 2 - 6.35mm |
Round: 6.35 - 44.45mm | |
Rectangle-flat: 20 x 120mm | |
Shape | round, drum-shaped, square, flat, bespoke order |
Application | electrolysis, electroplating, hydrometallurgy and metal anode electrolysis cell |
