Custom different size with logo
| Standard | ANSI B16.5 | Class 150 Flanges-Class 2500 Flanges |
| DIN | 6Bar 10Bar 16Bar 25Bar 40Bar 63Bar | |
| JIS | 5K Flanges-30K Flanges | |
| EN1092-1 | 6Bar 10Bar 16Bar 25Bar 40Bar 63Bar 100Bar | |
| Type | 1. Plate Flange 2. Flat Flange 3. Slip on Flange 4. Welding Neck Flange 5.Long Welding Neck Flange 6. Blind Flange 7. Socket Welding Flange 8. Thread Flange 9. Screwed Flange 10. Lap Joint Flange. etc. | |
| Connection Type | Raised Face, Flat Face, Ring Type Joint, Lap-Joint Face, Large Male-Female, Small Male-Female, Large Tongue, Groove, Small-Tongue, Groove, etc | |
| Size | 1/2"-100",SCH5S-SCH160S,XS,XXS,STD | |
| Heat Treatment | Normalizing, Annealing, Quenching Tempering | |
| Applications | Water works, Shipbuilding industry, Petrochemical & Gas industry, Power industry, Valve industry,and general pipes | |
Product name: Grade 5 Titanium Ring
ASNI ASME B16.5 titanium GR1 GR5 WN welding neck flange CL600
Material Grade: Titanium GR5
Standard: ASME SB381 / ASTM B381, AMS 4928
Size: OD200-1500mm * ID100-1200mm *Height20*600mm
Tecunique: Forged,CNC machined
Application: Electroplating, Chemical engineering & Petrochemical technology, Aviation etc.
| Categroy | Grade | Standard | Size(mm) | |||
| OD | ID | Height | Thickness | |||
| Ring materials |
Gr1.Gr2.Gr4. Gr5.Gr7.Gr9 |
ASME SB381 / ASTM B381, AMS 4928 |
200~400 | 100~300 | 35~120 | 40~150 |
| 400~700 | 150~500 | 40~160 | 40~250 | |||
| 700~900 | 300~700 | 50~180 | 40~300 | |||
| 900~1300 | 400~900 | 70~250 | 40~400 | |||
Welding neck flanges mainly have higher stiffness and load-bearing capacity of neck flanges. Its purpose is to transfer
the pressure of the pipeline, thereby reducing the Frankie high stress concentration butt welding flange, also known as hi
gh neck flange, rigid, suitable for high pressure and temperature occasions. The main production processes are integral f
orging, forging, pressing, casting, rolling and so on. The main production equipment is lathe, drilling machine, CNC mach
ine tools and so on. Applications: Boiler pressure vessel, petroleum, chemical industry, shipbuilding, pharmaceutical, met
allurgy,machinery, stamping elbow food and other industries.
Quality & Inspection:
1. PMI test to verify material grade.
2. Dimension controlling during fabricating and finished.
3. All of the products have been 100% press tested before shipping.
4. Packed in Fumigation-free plywood box.
5. Third party inspection available.
Q: Why choose us?
A1: We have 14 years experience for titanium products making.
A2: sample order is acceptable.
A3: lower price, good quality and short delivery time.
A4: 24 hours online service & quickly quote and delivery.
A5: ISO9001:2015 certification
A6: Give us drawing, make your drawings and ideas become a reality!
A7: Provide third-party quality inspection reports. quality assurance
