Grade 2 Grade 5 Titanium Weld Neck Flange Forged Size 15 NB To 1200NB

Large Image : Grade 2 Grade 5 Titanium Weld Neck Flange Forged Size 15 NB To 1200NB

Product Details:

Place of Origin:	China
Brand Name:	CDX
Certification:	ISO9001:2015 certification
Model Number:	CDX-F-2021046
Document:	Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity:	1 piece
Price:	Negotiable
Packaging Details:	plastic paper inside, plywood case outside
Delivery Time:	5-35 working days
Payment Terms:	L/C, T/T
Supply Ability:	1000 piece/week

Contact Now

Detailed Product Description

Name:	Titanium Flanges ASME Titanium Flange BS Flanges DIN Flanges	Titanium:	Grade 2, Grade 5
SIZE:	1/2″ (15 NB) To 48″ (1200NB)	Technology:	Forged And CNC Machining
Surface:	Pickling, Annealing, Bright, Sandblast, Hairline	Standard:	DIN ISO ASME B16.5
Press Rating:	0.6-32MPa
Highlight:	Grade 2 Titanium Weld Neck Flange , Grade 5 Titanium Weld Neck Flange , 1200NB Forged Weld Neck Flange Titanium

Titanium Flanges ASME titanium Flange BS Flanges DIN Flanges Neck Flanges titanium alloy

Custom titanium flange with logo

Dimensions :	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
SIZE	1/2″ (15 NB) to 48″ (1200NB)
CLASS/ PRESSURE	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
DIN	DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673
Flange Face Type	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Surface	pickling, annealing, bright, sandblast, hairline
Test Certificates	EN 10204/3.1B
	Raw Materials Certificate
	100% Radiography Test Report
	Third Party Inspection Report, etc
Type:	Plate Flange, Flat Flange, Slip on Flange, Welding Neck Flange, Long Welding Neck Flange, Blind Flange, Socket Welding Flange, Thread Flange, Screwed Flange, Lap Joint Flange
Connection Type	Raised Face, Flat Face, Ring Type Joint, Lap-Joint Face, Large Male-Female, Small Male-Female, Large Tongue, Groove, Small Tongue, Groove.

Grade 2 Grade 5 Titanium Weld Neck Flange Forged Size 15 NB To 1200NB 0

Quality & Inspection:

1. PMI test to verify material grade.
2. Dimension controlling during fabricating and finished.
3. All of the products have been 100% press tested before shipping.
4. Packed in Fumigation-free plywood box.
5. Third party inspection available.

Available Flange types

a.Slip On Flange

b.Welding Neck Flange

c.Threaded Flange(Screwed Flange)

d.Plain Flange

e.Blind Flange

f.Lap Joint Flange

g.Wocket Welding Flange

h. welded flange

i.titanium large-diameter flange

Welcome to contact us for detail
