Square Titanium Clad Copper Bar For Electrowinning Electroplating Electrolysis

5 piece
MOQ
Negotiable
Price
Square Titanium Clad Copper Bar For Electrowinning Electroplating Electrolysis
Features Gallery Product Description Request A Quote
Features
Specifications
Keyword: Square Titanium Clad Copper Rod For Electrowinning/electroplating/electrolysis
Standard: ASTM B432
Shape: Squre Or As Order
Material: Pure Titanium Gr2 Copper T2 Or As Order
Advantage:: Acid Resistance High Performance
Package: Plywood Case
High Light:

Electrowinning Titanium Clad Copper Bar

,

Electroplating Titanium Clad Copper Bar

,

Electrolysis Titanium Square Bar

Basic Infomation
Place of Origin: China
Brand Name: CDX
Certification: ISO9001:2015 certification
Model Number: CDX-C-2021-028
Payment & Shipping Terms
Packaging Details: plywood case
Delivery Time: 5-35 working days
Supply Ability: 500 piece/week
Product Description

square titanium clad copper rod for electrowinning/electroplating/electrolysis



Our Ti-Clad-Cu specification

Base metal: Cu(T2,TU2),AL,etc.

Coat: Ti,Ni,Zr,Stainless Steel 316L, etc.

Thickness of clad metal: 0.5 mm to 3.2 mm

Specification: ASTM B432

Standards: GB/T12769-2003

Available shape: round rod, square bar, rectangle bar

Technology: metallurgical bonding by explosive rolled

Square Titanium Clad Copper Bar For Electrowinning Electroplating Electrolysis 0Square Titanium Clad Copper Bar For Electrowinning Electroplating Electrolysis 1Square Titanium Clad Copper Bar For Electrowinning Electroplating Electrolysis 2

Product Name titanium copper rod
Material titanum&copper
Color Metallic
Standard Industrial
Grade N/A
Process method Hot Rolled,Forged
Specification as required
Dlivery time 7-10 days
Package Wooden case
Surface acid surface or polishing, sand blasted surface
Shape Round, flat, square, hexagonal
Used Widely use for aerospace, industry and medical聽
Application It is mainly used as a rack in electroplating, electrolysis, hydrometallurgy and other processes. It not only ensures the original
electrical conductivity ofcopper, but also protects the copper body from corrosion by titanium coating, and greatly reduces
electroplating and electrolysis.







Detail spec:

Shape/Size(mm) Round: φ(2~80)×(0.5~3.0)

Barrel: φ(25,27,29,32,34)×14×(1.0~2.0)

Square: (10~40)X(1.0~2.0) Flat: W(10~100)×H(10~30)

Types available: Ti-Cu/Steel bar/plate/tube/block etc.

Radius Transition:(3~5)
Application: Electrolysis, Plating, Hydrometallurgy,Oil and Chemcial indurty, etc.
