ASTM B265 Ti-6AL-4V grade 5 titanium plate F136 F67 medical use
annealed titanium and titanium alloy strip, sheet, and plate. ASTM B265 Ti and Ti-based alloy plates are widely used in the equipment for high-temperature environment, including aircraft equipment, petroleum and petrochemical, biomaterial, ocean and chemical industry, for example: blade, storage tank, target, tube and heat-exchanger equipment.
| Grades |
C max |
O max |
H max |
Fe max |
Al |
V |
| Grade1 |
0.08 |
0.18 |
0.015 |
0.20 |
/ |
/ |
| Grade2 |
0.08 |
0.25 |
0.015 |
0.30 |
/ |
/ |
| Grade5 |
0.08 |
0.20 |
0.015 |
0.40 |
5.50~ 6.75 |
3.50~ 4.50 |
| Grade 12 |
0.08 |
0.25 |
0.015 |
0.30 |
/ |
/ |
ASTM B265 Commonly used grades Mechanical Properties (%):
| Grades |
Yield Point Mpa (N/mm2) |
Tensile Strength Mpa (N/mm2) |
Elongation% min |
| Grade1 |
138~ 310 |
242 |
24 |
| Grade2 |
276~ 448 |
345 |
20 |
| Grade5 |
828 |
897 |
10 |
| Grade 12 |
345 |
483 |
18 |
Usually we provide a quality inspection report with the goods, which shows the chemical composition and physical properties
Size:
Thickness:5~100mm, Width:1200~2500mm, length:3000~10000mm
Appliation:Used in: aerospace, military advisor, industrial processes, automotive, agri-food, medicine, etc.
Unalloyed Titanium grades:
Grade 1,Grade 2,Grade 3,Grade 7,Grade 11 (CP Ti-0.15Pd),Grade 16,Grade 17,Grade 26,Grade 27
Titanium Based Alloys grades:
Grade 5(Ti-6Al-4V),Grade 9 ( Ti 3Al-2.5V),Grade 12 (Ti-0.3-Mo-0.8Ni),Grade 19 (Ti Beta C),Grade 23 (Ti 6Al-4V ELI),Grade 28
Grades of supply:Gr1 ,Gr2 ,Gr5,Gr12
ASTM B265 Commonly used grades Chemical Composition:
Welcome to contact us for further information
