Titanium Plate Gr.2 Medical Titanium Plate Gr.5 Rolled Titanium Plate
Titanium plate
Medical titanium plate
Rolled titanium plate
Hot rolled titanium plate cold rolled titanium plate
Titanium industry plate
Titanium Plate, High, 4x8 sheet metal prices titanium mini sheet plate,
ASTM B265 titanium metal surgical plate price and titanium armor plate,
anodized titanium plate G5 cutting titanium sheet metal
| Item Name | Titanium plate |
| Application | Metallurgy, electronics, petroleum, aerospace Industry, Medical, Surgical plant, Aerospace, Chemical industry Electronic industry Mechanical engineering |
| Type | GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18 |
| Standard | ASTM B265, AMS4911, AMS4911H, ASTM F136, ASTM F67 GB/T3621-2007 |
| Specification | Hot Rolling: Length 1000-4000mm,Width 400-3000mm,Thickness 4.1-60mm |
| Cold Rolling :Length 1000-3000mm,Width 400-1500mm,Thickness 0.3-3.0mm | |
| Certificate | ISO 9001:2008 |
| Supply Ability | 10 Tons per Month |
| Delivery | Within 5~35 days |
| Grade | Grade 1: Pure Titanium, relatively low strength and high ductility. |
| Grade 2: The pure titanium most used. The best combination of strength, weldability. | |
| Grade 3: High strength Titanium, used for Matrix-plates in shell and tube heat exchangers. | |
| Grade 5: The most manufactured titanium alloy. Exceedingly high strength. high heat resistance. | |
| Grade 7: Superior corrosion resistance in reducing and oxidizing environments. | |
| Grade 9: Very high strength and corrosion resistance. | |
| Grade 12: Better heat resistance than pure Titanium. Applications as for Grade 7 and Grade 11. | |
| Grade 23: Titanium-6Aluminum- 4Vanadium ELI. Alloy for surgical implant application. |
| Grade | N | C | H | Fe | O | Al | V | Pa | Mo | Ni | Ti |
| Gr1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | / | / | / | / | / | bal |
| Gr2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | / | / | bal |
| Gr3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | / | / | / | / | / | bal |
| Gr4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | / | / | / | / | / | |
| Gr5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | / | / | / | bal |
| Gr7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | 0.12~0.25 | / | / | bal |
| Gr9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | / | / | / | bal |
| Gr12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | / | / | / | 0.2~0.4 | 0.6~0.9 |
bal
|
| Grade | Tensile strength(min) | Yield Strength(min) | Elongation(%) | ||
| ksi | MPa | ksi | MPa | ||
| Gr1 | 35 | 240 | 20 | 138 | 24 |
| Gr2 | 50 | 345 | 40 | 275 | 20 |
| Gr3 | 65 | 450 | 55 | 380 | 18 |
| Gr4 | 80 | 550 | 70 | 483 | 15 |
| Gr5 | 130 | 895 | 120 | 828 | 10 |
| Terms of trade | EXW, FOB, CIF |
| Terms of payment | T/T, L/C |
| Packing | Carton box |
| Delivery time | 7-35days |
| Sample | support |
| MOQ | 10 pieces |
| Certification | ISO9001:2015 certification |
| Business Type | Manufacturer, Foreign Trading |
Q: Why choose us?
A1: We have 14 years experience for titanium products making.
A2: sample order is acceptable.
A3: lower price, good quality and short delivery time.
A4:The quotation can be make within 24 hours.
A5: ISO9001:2015 certification
A6: Give us drawing, make your drawings and ideas become a reality!
A7: Provide third-party quality inspection reports.
Welcome to contact us for further information !
