ASTM B265 Titanium Alloy Plate . Cold Rolled Thin Titanium Sheet 0.3-60mm Thickness

10kg
MOQ
Negotiable
Price
ASTM B265 Titanium Alloy Plate . Cold Rolled Thin Titanium Sheet 0.3-60mm Thickness
Features Gallery Product Description Request A Quote
Features
Specifications
Grade: Gr.1 Gr.2 Gr.5 Gr.7 Gr.9 Gr.23
Application: Industry, Medical Surgical Plant
Technique: Cold Rolled, Hot Rolled, Carved, Forged
Width: 400-3000mm, Max 2000mm, Customized,
Ti (min): 99.6%, 99%, 99.95%, 99 Min, 87.6%
Length: 1000-6000mm, Max 6000mm, Customized, <6, 6000mm Or Customized
Density: 4.51g/cm3
Standard: ASTM B265,ASME SB265,ASTMB265,GB/T 3621-2007,DIN 17860-90
Shape: Plate,sheet,round Plate/square Plate,Square,Straight
Thickness: 0.3-60mm,4.1~ 60,0.02mm-100mm,0.5-100mm
Keyword: Titanium Sheet Metal Prices,Titanium Metal Price Per Kg,Titanium Plate,Titanium Alloy Round Bar,1mm Titanium Sheet
High Light:

ASTM B265 Titanium Alloy Plate

,

Cold Rolled Titanium Alloy Plate Grade 5

,

0.3mm Thin Titanium Sheet

Basic Infomation
Place of Origin: China
Brand Name: CDX
Certification: ISO9001:2015 certification
Model Number: CDX-TB-2021-08
Payment & Shipping Terms
Packaging Details: plywood case
Delivery Time: 5-35days
Payment Terms: L/C, T/T
Supply Ability: 50000 kg per month
Product Description

ASTM B265 Titanium Alloy Grade 5 Shim Sheet, Titanium Alloy Grade 5 Plate, Titanium Alloy Gr 5 Sheets

ASTM B265 titanium and titanium alloy sheet

ASTM B265 covers annealed titanium and titanium alloy strip, sheet, and plate. ASTM B265 Ti and Ti-based alloy plates are widely used in the equipment for high-temperature environment, including aircraft equipment, petroleum and petrochemical, biomaterial, ocean and chemical industry, for example: blade, storage tank, target, tube and heat-exchanger equipment.



Item Name ASTM B265 Titanium Alloy Grade 5 Shim Sheet, Titanium Alloy Grade 5 Plate, Titanium Alloy Gr 5 Sheets
Application Metallurgy, electronics, petroleum, aerospace Industry, Medical, Surgical plant, Aerospace, Chemical industry Electronic industry Mechanical engineering
Type GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18
Standard ASTM B265, AMS4911, AMS4911H, ASTM F136, ASTM F67 GB/T3621-2007
Specification Hot Rolling: Length 1000-4000mm,Width 400-3000mm,Thickness 4.1-60mm
Cold Rolling :Length 1000-3000mm,Width 400-1500mm,Thickness 0.3-3.0mm
Certificate ISO 9001:2008
Supply Ability 10 Tons per Month
Delivery Within 5~35 days
Grade Grade 1: Pure Titanium, relatively low strength and high ductility.
Grade 2: The pure titanium most used. The best combination of strength, weldability.
Grade 3: High strength Titanium, used for Matrix-plates in shell and tube heat exchangers.
Grade 5: The most manufactured titanium alloy. Exceedingly high strength. high heat resistance.
Grade 7: Superior corrosion resistance in reducing and oxidizing environments.
Grade 9: Very high strength and corrosion resistance.
Grade 12: Better heat resistance than pure Titanium. Applications as for Grade 7 and Grade 11.
Grade 23: Titanium-6Aluminum- 4Vanadium ELI. Alloy for surgical implant application.


ASTM B265 Titanium Alloy Plate . Cold Rolled Thin Titanium Sheet 0.3-60mm Thickness 0ASTM B265 Titanium Alloy Plate . Cold Rolled Thin Titanium Sheet 0.3-60mm Thickness 1




Grade N C H Fe O Al V Pa Mo Ni Ti
Gr1 0.03 0.08 0.015 0.2 0.18 / / / / / bal
Gr2 0.03 0.08 0.015 0.3 0.25 / / / / / bal
Gr3 0.05 0.08 0.015 0.3 0.35 / / / / / bal
Gr4 0.05 0.08 0.015 0.5 0.4 / / / / /
Gr5 0.05 0.08 0.015 0.4 0.2 5.5~6.75 3.5~4.5 / / / bal
Gr7 0.03 0.08 0.015 0.3 0.25 / / 0.12~0.25 / / bal
Gr9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
Gr12 0.03 0.08 0.015 0.3 0.25 / / / 0.2~0.4 0.6~0.9

bal





Grade Tensile strength(min) Yield Strength(min) Elongation(%)
ksi MPa ksi MPa
Gr1 35 240 20 138 24
Gr2 50 345 40 275 20
Gr3 65 450 55 380 18
Gr4 80 550 70 483 15
Gr5 130 895 120 828 10





Usually we provide a quality inspection report with the goods, which shows the chemical composition and physical properties



Q: Why choose us?


A1: We have 14 years experience for titanium products making.
A2: sample order is acceptable.
A3: lower price, good quality and short delivery time.
A4:The quotation can be make within 24 hours.
A5: ISO9001:2015 certification
A6: Give us drawing, make your drawings and ideas become a reality!
A7: Provide third-party quality inspection reports.
